PowerVault ME412 Expansion Enclosure SpecificationsChassis Overview
Chassis format All-in-one: dual controllers, internal drive bays, networking and with expansion options
Rack size 2U or 5U
Controllers 2 hot-swappable per chassis (dual-active)
Single/dual controller support for 2U models
Dual controller support only for 5U model
Processor Intel® Xeon Processor
Internal storage ME4012: 12 x 3.5” drive bays (2.5” drive carriers supported)
System memory 8GB per controller
Expansion Capacity
Expansion enclosures ME412: 12 x 3.5” drive bays (12Gb SAS)
Min/Max drive count ME4012: 2/264
Max raw capacity1 ME4012: 3.1PB (with ME484 expansion)
NAS Support Supported with NX Series Windows NAS appliance
Storage media SAS and NL-SAS drives; different drive types, transfer rates, rotational speeds can be mixed in the same system:
• NLSAS (7.2K 3.5”): 4TB, 8TB, 10TB, 12TB, 12TB SED
• NLSAS (7.2K 2.5”): 2TB, 2TB SED
• SAS (10K 2.5”): 1.2TB, 1.8TB, 2.4TB, 2.4TB SED
• SAS (15K 2.5”): 900GB, 900GB SED
• SSD: 480GB, 960GB, 1.92TB, 1.92TB SED
• SDD and HDD: FIPS-certified SEDs
Network, Expansion Enclosure and I/O
Host interface FC, iSCSI, SAS (supports simultaneous multiprotocol FC/iSCSI)
Max 16Gb FC ports 8 per array (support auto-negotiate to 8Gb)
Max 10Gb iSCSI ports 8 SFP+ or BaseT ports per array (BaseT only support auto negotiate to 1Gb)
Max 12Gb SAS ports 8 12Gb SAS ports
Max multi-protocol ports 4 ports 16Gb FC SFP+
4 ports 10Gb iSCSI SFP+
Max management ports 2 per array (1Gb BASE-T)
Disk expansion protocol 12Gb SAS
Disk interface expansion ports 2 12Gb SAS (wide-Port) per array (1 port per controller)
Up to 9 2U expansion enclosures per 2U base array
Up to 3 5U expansion enclosures per 2U base array
Up to 3 5U expansion enclosures per 5U base array
